AQUASOLE AS600 large

Description

Designed to wash, rinse and dry soles of any material, it is composed of one washing module and one/two rinse modules. Thanks to the continuous rotation of the soles combined with low/high pressure washing jet and immersion washing, this plant allows to remove silicon perfectly.

Contattaci

Documentation

Advantages

Features

  • Vacuum dry
  • Swinging
  • Rotational
  • Flood and spray wash
  • Suitable for any kind of soles
  • Lower energetic consumption

Standard equipment

  • Stainless steel construction
  • Vacuum-tight system
  • Oil separator system
  • Touch screen
  • Tele assistance
  • Automatic dispenser

Optional equipment

  • Demineralizing system
  • Robotic load/unload of baskets
  • Customized baskets
  • Fume cleaner

Applications

Technical Features

MODELBASKET mmPAIR OF SOLES PER CYCLEOVERALL DIMENSIONSCYCLE TIME min.
AS600R with single rinse 600 x 800 x 6001000-12004740 x 2150 x 25606 – 10
AS600S with double rinse 600 x 800 x 6001000-12005500 x 2150 x 25606 – 10
